TRASPIR ALU 120, wysoce oddychająca membrana aluminiowana, która odbija ciepło.
Membrana wysoce oddychająca TRASPIR ALU 120 składa się z dwóch warstw: górnej aluminiowej i dolnej z oddychającej folii polipropylenowej. Dostępny jest również w formacie 3-metrowym.
Dokumentacja
| Technical data sheets | |
|---|---|
| Wskazówki dotyczące montażu |
TRASPIR ALU 120
| CODE | description | tape | H
[m]
|
L
[m]
|
A
[m²]
|
H
[ft]
|
L
[ft]
|
A
[sft]
|
pcs./pallet |
|---|---|---|---|---|---|---|---|---|---|
| TALU120 | TRASPIR SUNTEX 120 | - | 1.5 | 50 | 75 | 4.93 | 165 | 808 | 26 |
Technical Data
| Mass per unit area | EN 1849-2 | 120 g/m² | 0.39 oz/ft² |
|---|---|---|---|
| Thickness | EN 1849-2 | 0,6 mm | 24 mil |
| Water vapour transmission (Sd) | EN 1931 | 0,1 m | 34.965 PERM |
| MD/CD tensile strength | EN 12311-1 | 239 / 204 N/50mm | 27 / 23 lb/in |
| Elongation MD/CD | EN 12311-1 | 94 / 126 % | - |
| Resistance to nail tearing MD/CD | EN 12310-1 | 187 / 232 N | 42 / 52 lbf |
| Watertightness | EN 1928 | - | - |
| Thermal resistance | - | -20 / 80 °C | -4 / 176 °F |
| Reaction to fire | EN 13501-1 | class E | - |
| Resistance to penetration of air | EN 12114 | < 0,05 m³/(m²·h·50Pa) | < 0.003 cfm/ft² at 50Pa |
| Thermal conductivity (λ) | - | 0,3 W/(m·K) | 2.08 (BTU·in)/(h·ft²·°F) |
| Specific heat | - | 1800 J/(kg·K) | - |
| Density | - | ca. 200 kg/m³ | - |
| Water vapour resistance factor (μ) | - | ca. 166 | - |
| VOC content | - | 0 % | - |
| Reflectivity | EN 15976 | 81 % | - |
| UV stability | EN 13859-2 | 3 months | - |
| Exposure to weather | - | 2 weeks | - |
| After artificial ageing - watertightness | EN 1297 / EN 1928 | - | - |
| After artificial ageing - maximum tensile force MD/CD | EN 1297 / EN 12311-1 | 167 / 155 N/50mm | 19 / 18 lb/in |
| After artificial ageing - elongation | EN 1297 / EN 12311-1 | 56 / 75 % | - |
| Flexibility at low temperatures | EN 1109 | -40 / °C | -40 / °F |
| Equivalent thermal resistance with 50mm air gap (ε 0,025-0,88) | ISO 6946 | 0,804 / 0,502 (m²·K)/W | 4.57 / 2.85 (h·ft²·°F)/BTU |
Composition
| top layer | aluminium film |
|---|---|
| bottom layer | PP breathable film |
